Electro Conductive Powder T-1（Antimony doped tin oxide）
INTRODUCTION
Our Transparent Conductive Materials (TCM) consist of spherical primary particles with diameters shorter than the wavelength of visible ray. When a coating agent is made with a uniform dispersion of TCM, a transparent substrate can be attained with an anti-electrostatic performance. Made with tin oxide as a basic ingredient, TCM offers high performance against heat, chemicals, and severe weather.
EXAMPLE OF USE
- Antistatic(Please contact us if you are looking for antimony-free.)
- Electromagnetic shielding materials
- Near IR filters
- Heat ray filter
- Heat ray shielding
- Materials for controlling electrical current
- Refractive materials
FOR PRODUCTS
Electro Conductive Powder T-1（Sn-Sb oxide）
PHYSICAL AND CHEMICAL PROPERTIES
| Type | ATO | |
|---|---|---|
| Products | T-1 | |
| Chemical composition | SnO2 (Sb doped) | |
| Particle shape | Spherical | |
| Appearance | Blue | |
| Volume Resistivity | <5Ω・cm | |
| BET surface area | 70～85m2/g | |
| Features | Transparency | 〇 |
| Conductivity | 〇 | |
| Dispersibility | 〇 | |
| Environment | Sb doped | |
| Notes | High reliablity | |
DETAILS INTRODUCTION
